| Subtypes | |
| CM6800-32X6-X | CM6800 Series |
| Pelco | |
| Manufacturer | Pelco, Inc |
| Key Features | Video inputs / ports: 32 channels Video Outputs: 6 outputs |
| Video inputs / ports | 32 channels |
|---|---|
| Video Outputs | 6 outputs |
| No of Alarms | 8 alarms |
| Functions | |
| Signal Mode | PAL |
| TX/RX | RX/TX |
| Bandwidth MHz | 15 |
| Cross Talk dB | -55 |
| Video Signal V, ohms | 0.5 ~ 2 Vpp, 75 |
| Termination | BNC |
| Physical Specifications | Dimensions mm: 133 x 442 x 311 Weight g: 5220 |
| Electrical Specifications | Voltage: 230 V Power Consumption: 25 W |
| Environmental Specifications | Operating Temperature oC: -7 ~ +49 Operating Humidity %: 10 ~ 90, non-condensing |
| Analogue Switcher Type | Matrix Switchers |
| Additional info | Comes with desktop keyboard with variable speed joystick. With 7.62 m interconnect cable. |
| Download |
