| Subtypes | |
| NDN-832V03-IP | VFLEXIDOME IP 7000 RD |
| Basic Features | |
| Resolution | 2 MP/1080P |
| Image sensor type | 1/2.7‑inch CMOS |
| Max. frames per second (fps) | 30/1080P |
| Indoor / outdoor | Indoor/Outdoor |
| Day / night | Day/Night |
| Built in ir | x |
| Wide Dynamic Range | 76dB (model with IAE + 16dB) |
| ONVIF conformant | √ |
| Built-in microphone | x |
| Power over Ethernet (PoE) | √ |
| Advanced Features | |
| Compression | H.264 (ISO/IEC 14496-10); M- JPEG, JPEG |
| Multi-streaming | √ |
| Intelligent Dynamic Noise Reduction | √ |
| Intelligent streaming | √ |
| Intelligent Auto Exposure | √ |
| Remote commissioning | X |
| Privacy masking | √ |
| Region Of Interest (ROI) & E-PTZ | √ROI |
| Region Of Interest tracking | √ |
| No. of presets / guard tours | X |
| Wiper | X |
| Thermal | X |
| Alarm triggering | √ |
| Video analytics at the edge | √ |
| Tamper detection | √ |
| Video motion detection | √ |
| Audio detection | √ |
| Face detection | √ |
| PTZ Intelligent Tracking | X |
| Sensitivity | |
| Min. illumination day mode (color) | 0.22 luX |
| Min. Illumination night mode (B/W) | 0.05 lux |
| Starlight (extreme low-light) | X |
| Integrated IR-lighting | X |
| Optional IR-lighting | X |
| Lens | |
| Automatic Back Focus (ABF) | √ |
| Varifocal | √ |
| Automatic Varifocal (AVF) | x |
| Iris control | Automatic iris control |
| Focal length from | 3.8 mm |
| Focal length till | 13 mm |
| Horizontal Angle of View (HAoV) | 26° – 87° |
| Min. view angle (H) | 26º |
| Min. view angle (V) | 14.3º |
| Max. view angle (H) | 87º |
| Max. view angle (V) | 48º |
| DCRI distances (in m with 100 lux illumination) | |
| Detection | – |
| Classification | – |
| Recognition | – |
| Identification | – |
| Storage | |
| (micro)SD card slot | √ |
| Direct-to-iSCSI | √ |
| Cloud storage | √ |
| Connections | |
| Alarm input / output | √ |
| Audio in/out | √ |
| Hybrid | X |
| Confrontation monitor | X |
| 12VDC power output | 12VDC+24VDC |
| Housing | |
| Weather rating | IP66 & IP67 |
| Vandal resistant | Exceeding IK10 |
| Corrosion resistant | X |
| Operating temperature | -50° to 50° C |
| Downloads | |
| Datasheet (EN) | Download |
