| Subtypes | |
| NDV-5704-A | FLEXIDOME IP 4000i IR |
| Basic Features | |
| Resolution | 2 MP |
| Image sensor type | 1/2.9‑inch CMOS |
| Max. frames per second (fps) | 30 fps@1080p |
| Indoor / outdoor | Indoor/Outdoor |
| Day / night | Day/Night |
| Built in ir | √ |
| Wide Dynamic Range | 90dB |
| ONVIF conformant | √ |
| Built-in microphone | X |
| Power over Ethernet (PoE) | √ |
| Advanced Features | |
| Compression | H.265; H.264; M- JPEG |
| Multi-streaming | √ |
| Intelligent Dynamic Noise Reduction | √ |
| Intelligent streaming | √ |
| Intelligent Auto Exposure | X |
| Remote commissioning | X |
| Privacy masking | √ |
| Region Of Interest (ROI) & E-PTZ | √ROI |
| Region Of Interest tracking | X |
| No. of presets / guard tours | X |
| Wiper | X |
| Thermal | X |
| Alarm triggering | √ |
| Video analytics at the edge | √ |
| Tamper detection | √ |
| Video motion detection | √ |
| Audio detection | √ |
| Face detection | X |
| PTZ Intelligent Tracking | X |
| Sensitivity | |
| Min. illumination day mode (color) | 0.1 luX |
| Min. Illumination night mode (B/W) | 0 lux |
| Starlight (extreme low-light) | X |
| Integrated IR-lighting | √ |
| Optional IR-lighting | X |
| Lens | |
| Automatic Back Focus (ABF) | X |
| Varifocal | √ |
| Automatic Varifocal (AVF) | √ |
| Iris control | Automatic iris control |
| Focal length from | 3 mm |
| Focal length till | 10 mm |
| Horizontal Angle of View (HAoV) | 34° – 101° |
| Min. view angle (H) | 34° |
| Min. view angle (V) | 19° |
| Max. view angle (H) | 101° |
| Max. view angle (V) | 54° |
| DCRI distances (in m with 100 lux illumination) | |
| Detection | 32-126 m |
| Classification | 13-50 m |
| Recognition | 6-25 m |
| Identification | 3-13 m |
| Storage | |
| (micro)SD card slot | √ |
| Direct-to-iSCSI | √ |
| Cloud storage | √ |
| Connections | |
| Alarm input / output | √ |
| Audio in/out | √ |
| Hybrid | √ |
| Confrontation monitor | X |
| 12VDC power output | +12 VDC ±5%, 24 VAC ±10% or Power-over-Ethernet (48 VDC ) |
| Housing | |
| Weather rating | IP66 |
| Vandal resistant | IK10 |
| Corrosion resistant | X |
| Operating temperature | -40° to 50° C |
| Downloads | |
| Datasheet (EN) | Download |
