| Subtypes | |
| DIP-7184-4HD Appliance 4x4TB | DIVAR IP 7000 2U |
| Basic Features | |
| Max. System Size | 128 |
| Integrated Video Management | √ |
| RAID Level | RAID-5, RAID-6 |
| Supported Resolution | CIF/2CIF/4CIF/720p/1080p/5MP/UHD |
| Video Compression | H.264, H.265, MPEG-4, ONVIF, RTSP, JPEG |
| Transcoding | √ |
| ONVIF | √ |
| Mechanical | |
| Form Factor | 2U 19-inch Rack Mount |
| Network Connections (LAN) | 2x Gigabit Ethernet, 1x 100Mbit (Mgmt) |
| USB Ports | 4x USB 2.0, 2x USB 3.0 |
| Number of Power Supplies | 2 |
| Power Supply Hot Swappable | √ |
| Video Output | |
| Connector Type | 4x mini-DP |
| Spot monitor | – |
| Audio | |
| In/Out Channels | 128 |
| Compression Type | G.726 |
| Recording | |
| Video Recording Management | √ |
| Schedule Recording Modes | √ |
| Storage Options | |
| Max. Drive Supported | 4 x 4 TB |
| Available Capacities Per Drive | 3, 4, 6 or 8 TB |
| Base System Capacity TB | 0, 12, 16, 24, 32, 48 or 64 TB |
| Max. Base Capacity TB | 6 x 4 TB |
| Full System Capacity TB | 576 TB |
| Storage Extensions | |
| Max. Number of Units | 4x DIVAR IP 6000 |
| Max. Drive Supported | 4, 6 or 8 |
| Available Capacity per Drive | 3, 4, 6 or 8 TB |
| Hot Swappable | √ |
| Redundancy | |
| Power Supply Redundancy | √ |
| Hot-Swappable HDD | √ |
| Software Options | |
| PTZ Control | √ |
| CCTV Keyboard Support | √ |
| Admin Control | √ |
| Export Option | √ |
| Remote Access | |
| Mobile Device | Video security app |
| Network | 10/100/1000 Ethernet |
| Web Browser Access | √ |
| Advanced Feature Support | |
| Forensic Search Support | √ |
| Web Client | √ |
| Downloads | |
| Datasheet (EN) | Download |
