| Subtypes | |
| DVR-XS400-A HDD expansion 4TB | DIVAR hybrid 5000 recorder |
| Basic Features | SURVEILLANCE HDD EXPANSION |
| Max. System Size | 16 analog + 16IP or 32IP |
| Integrated Video Management | X |
| RAID Level | RAID-1, RAID-5 |
| Supported resolutions IP cameras Supported resolutions AN cameras | up to 12MP up to 960H |
| Video Compression | H.264, H.265, MPEG-4 |
| Transcoding | X |
| ONVIF | √ |
| Mechanical | |
| Form Factor | 1.5U high Rack Mount |
| Network Connections (LAN) | 2x Gigabit Ethernet |
| USB Ports | 1x USB 2.0, 2xUSB 3.0 |
| Number of Power Supplies | 1 |
| Power Supply Hot Swappable | X |
| Video Output | |
| Connector Type | VGA, HDMI |
| Spot monitor | HDMI |
| Audio | |
| In/Out Channels | 4 in / 1 out |
| Compression Type | G.726 |
| Recording | |
| Video Recording Management | √ |
| Schedule Recording Modes | √ |
| Storage Options | 24/7 SURVEILLANCE HDD EXPANSION |
| Max. Drive Supported | kit. 4 TB |
| Available Capacities Per Drive | 1, 2, 3, 4 or 6TB |
| Base System Capacity TB | 0, 4 TB |
| Max. Base Capacity TB | 24 TB |
| Full System Capacity TB | 24 TB |
| Storage Extensions | |
| Max. Number of Units | 1 |
| Max. Drive Supported | 1 |
| Available Capacity per Drive | 1, 2, 3, 4 or 6TB |
| Hot Swappable | X |
| Redundancy | |
| Power Supply Redundancy | X |
| Hot-Swappable HDD | X |
| Software Options | |
| PTZ Control | √ |
| CCTV Keyboard Support | X |
| Admin Control | √ |
| Export Option | √ |
| Remote Access | |
| Mobile Device | Mobile Viewer app |
| Network | 10/100/1000 Ethernet |
| Web Browser Access | √ |
| Advanced Feature Support | |
| Forensic Search Support | X |
| Web Client | √ |
| Downloads | |
| Datasheet (EN) | Download |
