| Subtypes | |
| EVO-05LID | Evolution 05 Mini 360° Indoor Camera The next step in 360° total situational awareness |
| Basic Features | |
| Resolution | ۵MP |
| Image sensor type | ۲۵۹۲ H x 1944 V, 5 MP, ۱/۲.۵-inch Sony CMOS Sensor |
| Max. frames per second (fps) | ۳۰ fps video stream at 1 MP and ¼ MP |
| Indoor / outdoor | Indoor |
| Day / night | √ |
| Built in ir | X |
| Wide Dynamic Range | >60 dB |
| ONVIF conformant | √ |
| Built-in microphone | X |
| Power over Ethernet (PoE) | √ |
| Advanced Features | |
| Compression | H.264 |
| Multi-streaming | √ |
| Intelligent Dynamic Noise Reduction | X |
| Intelligent streaming | |
| Intelligent Auto Exposure | √ |
| Remote commissioning | X |
| Privacy masking | X |
| Region Of Interest (ROI) & E-PTZ | X |
| Region Of Interest tracking | X |
| No. of presets / guard tours | X |
| Wiper | X |
| Thermal | X |
| Alarm triggering | X |
| Video analytics at the edge | X |
| Tamper detection | X |
| Video motion detection | √ |
| Audio detection | X |
| Face detection | X |
| PTZ Intelligent Tracking | √ |
| Sensitivity | |
| Min. illumination day mode (color) | ۰.۲ lux = 50 IRE F/2.0 (6500 K) |
| Min. Illumination night mode (B/W) | ۰.۲ lux = 50 IRE F/2.0 (6500 K) |
| Starlight (extreme low-light) | X |
| Integrated IR-lighting | X |
| Optional IR-lighting | X |
| Lens | |
| Automatic Back Focus (ABF) | X |
| Varifocal | X |
| Automatic Varifocal (AVF) | X |
| Iris control | X |
| Focal length from | X |
| Focal length till | X |
| Horizontal Angle of View (HAoV) | |
| Min. view angle (H) | X |
| Min. view angle (V) | X |
| Max. view angle (H) | X |
| Max. view angle (V) | X |
| DCRI distances (in m with 100 lux illumination) | |
| Detection | √ |
| Classification | X |
| Recognition | X |
| Identification | X |
| Storage | |
| (micro)SD card slot | Built-in microSD card slot. Supports cards up to 128 GB capacity. Speed class 10 or higher required |
| Direct-to-iSCSI | X |
| Cloud storage | X |
| Connections | |
| Alarm input / output | X |
| Audio in/out | X |
| Hybrid | X |
| Confrontation monitor | X |
| ۱۲VDC power output | √ |
| Housing | |
| Weather rating | IP40 |
| Vandal resistant | IK10 |
| Corrosion resistant | X |
| Operating temperature | ۰ to +40°C (-32 to +104°F) |
| Downloads | |
| Datasheet (EN) | Download |
