| Subtypes | |
| NBN-80052-BA | DINION IP 8000 HD |
| Basic Features | |
| Resolution | 5MP |
| Image sensor type | 1/1.8‑inch CMOS |
| Max. frames per second (fps) | 30 fps@ 5MP (3K) |
| Indoor / outdoor | Indoor/Outdoor(WITH HOUSING) |
| Day / night | Day/Night |
| Built-in IR | X |
| Wide Dynamic Range | 97+16db |
| ONVIF conformant | √ |
| Built-in microphone | X |
| Power over Ethernet (PoE) | √ |
| Advanced Features | |
| Compression | H.264 (MP); M- JPEG |
| Multi-streaming | √ |
| Intelligent Dynamic Noise Reduction | √ |
| Intelligent streaming | √ |
| Intelligent Auto Exposure | X |
| Remote commissioning | X |
| Privacy masking | √ |
| Region Of Interest (ROI) & E-PTZ | √ROI& E-PTZ |
| Region Of Interest tracking | √ |
| No. of presets / guard tours | X |
| Wiper | X |
| Thermal | X |
| Alarm triggering | √ |
| Video analytics at the edge | √ |
| Tamper detection | √ |
| Video motion detection | √ |
| Audio detection | √ |
| Face detection | X |
| PTZ Intelligent Tracking | X |
| Sensitivity | |
| Min. illumination day mode (color) | 0.0121 lx (5mp) & 0.00825 lx (2mp) |
| Min. Illumination night mode (B/W) | 0.004 lx |
| Starlight (extreme low-light) | √ |
| Integrated IR-lighting | X |
| Optional IR-lighting | X |
| Lens | |
| Automatic Back Focus (ABF) | X |
| Varifocal | X |
| Automatic Varifocal (AVF) | X |
| Iris control | Automatic iris control |
| Focal length from | X |
| Focal length till | X |
| Horizontal Angle of View (HAoV) | – |
| Min. view angle (H) | – |
| Min. view angle (V) | – |
| Max. view angle (H) | – |
| Max. view angle (V) | – |
| DCRI distances (in m with 100 lux illumination) | |
| Detection | – |
| Classification | – |
| Recognition | – |
| Identification | – |
| Storage | |
| (micro)SD card slot | √ |
| Direct-to-iSCSI | √ |
| Cloud storage | √ |
| Connections | |
| Alarm input / output | √ |
| Audio in/out | √ |
| Hybrid | √ |
| Confrontation monitor | √ |
| 12VDC power output | PoE and +12 VDC |
| Housing | |
| Weather rating | X |
| Vandal-resistant | X |
| Corrosion-resistant | X |
| Operating temperature | -30° to 50° C |
| Downloads | |
| Datasheet (EN) | Download |
