| Subtypes | |
| V-7506 | Straight Plug twist On |
| Electrical Characteristics | |
| Impendence | Non-Constant |
| Frequency Range | 0-2 GHz |
| Insulation resistance | 5000 Megaohms min. |
| Contact resistance | |
| Center Contact | 3 milliohms Max |
| Outer conductor | 2 milliohms Max |
| Working voltage in VRMS (at sea level) | 335 VRMS Max at sea level |
| Dielectric withstanding voltage in VRMS (at sea level) | 1000 VRMS min at sea level |
| Mechanical Characteristics | |
| Durability | 500 matings |
| Force to engage and disengage | 2 in-lbs Max |
| Proof torque | 15 in-lbs min |
| Coupling nut retention force | 80 lbs min |
| Center contact retention force | 6 lbs min |
| Environmental Characteristics | |
| Temperature Range | -65°C to +165°C |
| Corrosion (salt spray) | MIL-STD-202 Method 101 Test Cond B |
| Vibration | MIL-STD-202 Method 204 Test Cond B |
| Shock | – |
| Materials | |
| Body(nut)/Center Male contact/Outer Contact | Brass |
| Center female contacts | Brass / Beryllium Copper |
| Ferrules | Brass |
| Insulator | Teflon |
| Plating | |
| Body | Nickel |
| Coupling nut / Design | Nickel |
| Center Contact | Gold |
| Outer Contacts / Design | Nickel |
| 12VDC power output | 24 VAC or +12 VDC |
| Downloads | |
| Datasheet (EN) | Download |
