Subtypes | |
V631272 | Mega Six, Category 6 SFTP |
Insulation | |
Material | Solid Polyethylene |
Nominal Diameter (mm) | ۱.۱±۰.۰۲ |
Conductor | |
Composition (No./M) | ۱/۰.۵۷±۰.۰۲mm |
Material | Annealed Copper Wire |
Outside Diameter (mm) | ۰.۵۷ |
AWG (Solid) | ۲۳ |
Center Cross Filler | Solid PE Cross Filler |
Drain wire | Tinned Copper |
Jacket/Sheath | |
Material | LSZH |
Braiding Percentage | ۶۰% |
Thickness diameter (mm) | ۰.۴۷ |
Overall Diameter (mm) | ۷.۶ ± ۰.۳ mm |
Color | Violet |
Application | -Horizontal Network and Voice in Structured Cabling system -۱۰/۱۰۰/۱۰۰۰ Base-T(IEEE 802.3) -۱۵۵Mbps ATM -ANSI X3.263: 100Mbps -۴/۱۶ Mbps Token Ring(IE802.3) -۳D imaging -۱۰۰Mbps TP-PMD |
Datasheet (EN) | Download |
