| Specifications | ||
| Manufacturer | Cisco Systems, Inc | |
| Manufacturer Part Number | WS-C3560CX-12PD-S | |
| Brand Name | Cisco | |
| Product Line | Catalyst | |
| Product Series | 3750-E | |
| Product Model | 3750E-48PD-S | |
| Network management Interface | ● Ethernet management port: RJ-45 connectors, 4-pair Cat-5 UTP cabling ● Management console port: RJ-45-to-DB9 cable for PC connections | |
| Layer 3 Switch | ||
| Available PoE Power | 435W | |
| Switching Capacity | 92Gbps | |
| Maximum stacking number | up to 9 switches with same IOS feature set in same series | |
| Stack Bandwidth | 480Gbps | |
| Forwarding Performance | 68.4Mpps | |
| FNF entries | 24,000 flows | |
| Maximum VLANs IDs | 1,000 | |
| MAC Address Table Size | 32K | |
| CPU | Multicore CPU | |
| RAM | 4 G | |
| Flash Memory | 2 G | |
| Wireless | ||
| Number of AP per switch/stack | 100 | |
| Number of wireless clients per switch/stack | 2000 | |
| Total number of WLANs per switch | 64 | |
| Wireless bandwidth per switch | up to 20Gbps | |
| Supported Aironet AP series | 3600, 3500, 2600, 1600, 1260, 1140, 1040 | |
| Expansion / Connectivity | ||
| Console ports | USB (Type-B), Ethernet (RJ-45) | |
| Expansion Slot(s) | 1 network module slot and 1 power redundant slot | |
| Network Modules Selection | ● C3850-NM-4-1G: 4 x 1G uplinks network module ●C3850-NM-2-10G: 2 x 10G or 4 x 1G uplinks network module | |
| Stacking cable | ●STACK-T1-50CM StackWise stacking cable with a 0.5 m length ●STACK-T1-1M StackWise stacking cable with a 1.0 m length ●STACK-T1-3M StackWise stacking cable with a 3.0 m length | |
| Stack Power Cable (recommended) | ●CAB-SPWR-30CM stack power cable with a 30CM length ●CAB-SPWR-150CM stack power cable with a 150CM length | |
| Power supply | PWR-C1-715WAC | |
| Power Device | Power supply – redundant – plug-in module | |
| Power Redundancy | optional | |
| Voltage range (Auto) | 100V-240V | |
| Power Consumption of standalone(in Watts) | 88.32 (max) | |
| Width/Depth/Height | 44.5 cm/44.5 cm4.45 CM | |
| Rack Mounting Kit | optional | |
MTBF in hours | 269/450 | |
| Compliant Standards | ● IEEE 802.1D Spanning Tree Protoco ● IEEE 802.3 10BASE-T ●IEEE 802.3af and IEEE 802.3at | |
| System software / license | ||
System software | IOS LAN Base (Upgradable) | |
| EnergyWise license | ENERGY-MGMT, ENERGY-MGT-100-K9 | |
| Software license | ●C3850-24-L-S : LAN Base to IP Base RTU paper license | |
| Access Point Licenses | ●L-LIC-CT3850-UPG: Primary upgrade license SKU for Cisco 3850 wireless controller (e-delivery) | |
| Features | ●RPS Support ● Jumbo Frames ● VLANS ●Voice Vlan ●VTPv2 ●CDPv2 ●LLDP ● 802.3ad LACP and PAgP ● PVST/PVST+ ● 802.1W/802.1S ●Port Fast/Uplink Fast ●Dynamic Trunking Protocol (DTP) ● port CoS Trust and Override ● Trusted Boundary ● ACL Classification ●ingress Policing ● Auto QoS ● Per VLAN policies ● 802.1p queues ● Scheduling ● Priority Queuing ● Configure CoS Priority Queues ●Configure CoS Priority Queues ● Configure Queue Weights ● Configure Buffers and Thresholds ●Class & Policy Maps ● Modify CoS and DSCP Mapping ● Weighted Tail Drop ● IGMPv1,v2,v3 and MLDv1, v2 ● DHCP server ● DSCP transparency ● HSRP, VRRP, BLGP ● RIPv1, v2 EIGRP, PIM OSPF, OSPFv3, EIGRPv6, BGPv4, IS-ISv4 ● VRF-lite ● PIM-SM/DM, PIM sparse-dense mode, SSM ● Flexible Netflow | |
| Advanced Network security | ● Port security ● DHCP snooping ●Dynamic ARP inspection (DAI) ● IP source guard ●The Unicast Reverse Path Forwarding (uRPF) | |
| Management | ●BRIDGE-MIB ●CISCO-AUTH-FRAMEWORK-MIB ●CISCO-SNMP-TARGET-EXT-MIB ●CISCO-STACKMAKER-MIB | |
| Technical Support and Services | ● Cisco SMARTnet Service ● Cisco Smart Foundation Service ● Cisco SP Base Service ● Cisco Focused Technical Support Services | |
| Environmental Ranges | ||
| With AC power supply Operating environment and altitude | ||
Operating temperature up to 5000 ft (1500 m) | 23ºF to 113ºF (-5ºC to +45ºC) | |
Operating temperature up to 10,000 ft (3000 m) | 23ºF to 104ºF (-5ºC to +40ºC) | |
Short-term exception at sealevel with single fan failure | 23ºF to 113ºF (-5ºC to +45ºC) | |
Short-term exception up to 5000 feet (1500 m) | 23ºF to 122ºF (-5ºC to 50ºC) | |
Short-term exception up to 10,000 feet (3000 m) | 23ºF to 113ºF (-5ºC to 45ºC) | |
With DC power supply Operating environment and altitude (NEBS) | ||
Operating temperature up to 6000 ft (1800 m) | 23ºF to 113ºF (-5ºC to +45ºC) | |
Operating temperature up to 10,000 ft (3000 m) | 23ºF to 104ºF (-5ºC to +40ºC) | |
Operating temperature up to 13,000 ft (4000m) | 23ºF to 95ºF (-5ºC to 35ºC) | |
Short-term exception up to 6,000 feet (1800 m) | 23ºF to 131ºF (-5ºC to +55ºC) | |
Short-term exception up to 10,000 feet (3000 m) | 23ºF to 122ºF (-5ºC to +50ºC) | |
Short-term exception up to 13,000 feet (4000 m) | 23ºF to 113ºF (-5ºC to +45ºC) | |
Short-term exception at sealevel with single fan failure | 23ºF to 113ºF (-5ºC to +45º) | |
Storage environment | -40ºF to 160ºF (-40ºC to 70ºC) | |
Operating altitude | Up to 13,000 Feet (Up to 4000 Meters) | |
Storage altitude | Up to 15,000 Feet (Up to 4573 Meters) | |
Operating relative humidity | 10% to 95% noncondensing | |
Storage relative humidity | 10% to 95% noncondensing | |
