توضیحات
ABS (Adaptive Black Stretch) دید منطقه تیره را بدون کاهش کیفیت تصویر در منطقه روشن افزایش می دهد.
حساسیت بالا: ۰.۶ لوکس (رنگ) ، ۰.۰۴ لوکس (B / W) در F1.2
فیلتر برش IR خاموش / روشن می شود تا حساسیت را در حالت B / W افزایش دهد.
وضوح بالا: ۵۴۰ خط تلویزیون (رنگ)
NTSC/PAL | NTSC, PAL | |
|---|---|---|
TV System | ۵۴۰ | |
Temperature (degree, Celsius) | MAX | ۵۰ |
| MIN | -۱۰ | |
Power Source | ۱۲۰V AC, 22 | |
| Subtypes | |
| WV-CP290 | Supper Image Qality |
| Basic Features | |
| Resolution | ۴۹۴*۷۶۸ |
| Image sensor type | ۱/۳″ |
| Max. frames per second (fps) | |
| Indoor / outdoor | Outdoor |
| Day / night | Day/Night |
| Built in ir | √ |
| Wide Dynamic Range | ۵۰dB |
| ONVIF conformant | X |
| Built-in microphone | X |
| Power over Ethernet (PoE) | √ |
| Advanced Features | |
| Compression | |
| Multi-streaming | X |
| Intelligent Dynamic Noise Reduction | X |
| Intelligent streaming | X |
| Intelligent Auto Exposure | X |
| Remote commissioning | X |
| Privacy masking | X |
| Region Of Interest (ROI) & E-PTZ | X |
| Region Of Interest tracking | X |
| No. of presets / guard tours | X |
| Wiper | X |
| Thermal | X |
| Alarm triggering | |
| Video analytics at the edge | Intelligent Video Analytics |
| Tamper detection | √ |
| Video motion detection | √ |
| Audio detection | √ |
| Face detection | X |
| PTZ Intelligent Tracking | X |
| Sensitivity | |
| Min. illumination day mode (color) | ۰.۴ lux |
| Min. Illumination night mode (B/W) | ۰.۰۳ lux |
| Starlight (extreme low-light) | X |
| Integrated IR-lighting | X |
| Optional IR-lighting | X |
| Lens | CS-mount |
| Automatic Back Focus (ABF) | X |
| Varifocal | X |
| Automatic Varifocal (AVF) | X |
| Iris control | |
| Focal length from | |
| Focal length till | |
| Horizontal Angle of View (HAoV) | |
| Min. view angle (H) | |
| Min. view angle (V) | |
| Max. view angle (H) | |
| Max. view angle (V) | |
| DCRI distances (in m with 100 lux illumination) | |
| Detection | |
| Classification | |
| Recognition | |
| Identification | |
| Storage | |
| (micro)SD card slot | √ |
| Direct-to-iSCSI | √ |
| Cloud storage | √ |
| Connections | |
| Alarm input / output | √ |
| Audio in/out | √ |
| Hybrid | X |
| Confrontation monitor | X |
| ۱۲VDC power output | √ |
| Housing | |
| Weather rating | IP66 |
| Vandal resistant | IK10+ |
| Corrosion resistant | √ |
| Operating temperature | -۱۰ C (14 F to +50 C to +122 F) |
| Downloads | |
| Datasheet (EN) | Download |
