| Subtypes | |
| WV-S1531LNS | Network Camera |
| Basic Features | |
| Resolution | 1080p |
| Image sensor type | 1/3″ |
| Max. frames per second (fps) | 60fps |
| Indoor / outdoor | Indoor |
| Day / night | Day/Night |
| Built in ir | √ |
| Wide Dynamic Range | 144db |
| ONVIF conformant | √ |
| Built-in microphone | √ |
| Power over Ethernet (PoE) | √ |
| Advanced Features | |
| Compression | H.264; JPEG;H265 |
| Multi-streaming | √ |
| Intelligent Dynamic Noise Reduction | √ |
| Intelligent streaming | √ |
| Intelligent Auto Exposure | X |
| Remote commissioning | X |
| Privacy masking | √ |
| Region Of Interest (ROI) & E-PTZ | X |
| Region Of Interest tracking | X |
| No. of presets / guard tours | X |
| Wiper | X |
| Thermal | X |
| Alarm triggering | |
| Video analytics at the edge | Intelligent Video Analytics |
| Tamper detection | X |
| Video motion detection | √ |
| Audio detection | √ |
| Face detection | X |
| PTZ Intelligent Tracking | X |
| Sensitivity | |
| Min. illumination day mode (color) | 0.012 lux |
| Min. Illumination night mode (B/W) | 0.006 lux |
| Starlight (extreme low-light) | X |
| Integrated IR-lighting | X |
| Optional IR-lighting | X |
| Lens | |
| Automatic Back Focus (ABF) | √ |
| Varifocal | |
| Automatic Varifocal (AVF) | |
| Iris control | |
| Focal length from | 2.8-10mm |
| Focal length till | |
| Horizontal Angle of View (HAoV) | |
| Min. view angle (H) | 31° |
| Min. view angle (V) | 17° |
| Max. view angle (H) | 112° |
| Max. view angle (V) | 60° |
| DCRI distances (in m with 100 lux illumination) | |
| Detection | – |
| Classification | – |
| Recognition | – |
| Identification | – |
| Storage | |
| (micro)SD card slot | √ |
| Direct-to-iSCSI | √ |
| Cloud storage | √ |
| Connections | |
| Alarm input / output | √ |
| Audio in/out | √ |
| Hybrid | X |
| Confrontation monitor | X |
| 12VDC power output | √ |
| Housing | |
| Weather rating | IP66 |
| Vandal resistant | IK10 |
| Corrosion resistant | √ |
| Operating temperature | -40 C (-40F to +60C to +140F) |
| Downloads | |
| Datasheet (EN) | Download |
