| Subtypes | |
| ZN-NH22XE | 1080p IP Box Camera with Imbedded Intelligence Technology |
| Basic Features | |
| Resolution | 2MP |
| Image sensor type | 1/2.7″ 1080p CMOS |
| Max. frames per second (fps) | Up to 30@HD1080 |
| Indoor / outdoor | Indoor |
| Day / night | True Day/Night Performance |
| Built in ir | X |
| Wide Dynamic Range | √ |
| ONVIF conformant | √ |
| Built-in microphone | X |
| Power over Ethernet (PoE) | 12VDC |
| Advanced Features | |
| Compression | H.264, MJPEG |
| Multi-streaming | √ |
| Intelligent Dynamic Noise Reduction | X |
| Intelligent streaming | |
| Intelligent Auto Exposure | X |
| Remote commissioning | X |
| Privacy masking | X |
| Region Of Interest (ROI) & E-PTZ | X |
| Region Of Interest tracking | √ |
| No. of presets / guard tours | X |
| Wiper | X |
| Thermal | X |
| Alarm triggering | X |
| Video analytics at the edge | X |
| Tamper detection | √ |
| Video motion detection | √ |
| Audio detection | X |
| Face detection | X |
| PTZ Intelligent Tracking | X |
| Sensitivity | |
| Min. illumination day mode (color) | Color : 0.5 lux |
| Min. Illumination night mode (B/W) | BW : 0.001 lux (Sens-up 32X) |
| Starlight (extreme low-light) | X |
| Integrated IR-lighting | X |
| Optional IR-lighting | X |
| Lens | |
| Automatic Back Focus (ABF) | X |
| Varifocal | X |
| Automatic Varifocal (AVF) | X |
| Iris control | X |
| Focal length from | X |
| Focal length till | X |
| Horizontal Angle of View (HAoV) | |
| Min. view angle (H) | – |
| Min. view angle (V) | – |
| Max. view angle (H) | – |
| Max. view angle (V) | – |
| DCRI distances (in m with 100 lux illumination) | |
| Detection | √ |
| Classification | X |
| Recognition | X |
| Identification | X |
| Storage | |
| (micro)SD card slot | Built-in SD slot (SD card not included) (Recommend Class 4 and higher for HD recordings) |
| Direct-to-iSCSI | X |
| Cloud storage | X |
| Connections | |
| Alarm input / output | X |
| Audio in/out | √ |
| Hybrid | X |
| Confrontation monitor | X |
| 12VDC power output | √ |
| Housing | |
| Weather rating | – |
| Vandal resistant | – |
| Corrosion resistant | X |
| Operating temperature | 12VDC: 0 °C~ 50 °C (32 °F ~ 122 °F) PoE: 0 °C ~ 50 °C (32 °F ~ 122 °F) Up to 85% RH (Non-condensing) |
| Downloads | |
| Datasheet (EN) | Download |
