Subtypes | |
NDV-5704-A | FLEXIDOME IP 4000i IR |
Basic Features | |
Resolution | 2 MP |
Image sensor type | 1/2.9‑inch CMOS |
Max. frames per second (fps) | 30 fps@1080p |
Indoor / outdoor | Indoor/Outdoor |
Day / night | Day/Night |
Built in ir | √ |
Wide Dynamic Range | 90dB |
ONVIF conformant | √ |
Built-in microphone | X |
Power over Ethernet (PoE) | √ |
Advanced Features | |
Compression | H.265; H.264; M- JPEG |
Multi-streaming | √ |
Intelligent Dynamic Noise Reduction | √ |
Intelligent streaming | √ |
Intelligent Auto Exposure | X |
Remote commissioning | X |
Privacy masking | √ |
Region Of Interest (ROI) & E-PTZ | √ROI |
Region Of Interest tracking | X |
No. of presets / guard tours | X |
Wiper | X |
Thermal | X |
Alarm triggering | √ |
Video analytics at the edge | √ |
Tamper detection | √ |
Video motion detection | √ |
Audio detection | √ |
Face detection | X |
PTZ Intelligent Tracking | X |
Sensitivity | |
Min. illumination day mode (color) | 0.1 luX |
Min. Illumination night mode (B/W) | 0 lux |
Starlight (extreme low-light) | X |
Integrated IR-lighting | √ |
Optional IR-lighting | X |
Lens | |
Automatic Back Focus (ABF) | X |
Varifocal | √ |
Automatic Varifocal (AVF) | √ |
Iris control | Automatic iris control |
Focal length from | 3 mm |
Focal length till | 10 mm |
Horizontal Angle of View (HAoV) | 34° – 101° |
Min. view angle (H) | 34° |
Min. view angle (V) | 19° |
Max. view angle (H) | 101° |
Max. view angle (V) | 54° |
DCRI distances (in m with 100 lux illumination) | |
Detection | 32-126 m |
Classification | 13-50 m |
Recognition | 6-25 m |
Identification | 3-13 m |
Storage | |
(micro)SD card slot | √ |
Direct-to-iSCSI | √ |
Cloud storage | √ |
Connections | |
Alarm input / output | √ |
Audio in/out | √ |
Hybrid | √ |
Confrontation monitor | X |
12VDC power output | +12 VDC ±5%, 24 VAC ±10% or Power-over-Ethernet (48 VDC ) |
Housing | |
Weather rating | IP66 |
Vandal resistant | IK10 |
Corrosion resistant | X |
Operating temperature | -40° to 50° C |
Downloads | |
Datasheet (EN) | Download |
