| Subtypes | |
| CM 6800-48X 8-X(PAL) | CM6800E-48X8-X |
| Make | Pelco |
| Manufacturer | Pelco, Inc |
| Key Features | Video inputs / ports: 48 channels Video Outputs: 8 outputs Functions: PTZ |
| Video inputs / ports | ۴۸ channels |
|---|---|
| Video Outputs | ۸ outputs |
| Functions | PTZ |
| Signal Mode | PAL |
| TX/RX | RX/TX |
| Bandwidth MHz | ۱۵ |
| Cross Talk dB | -۵۵ |
| Video Signal V, ohms | ۰.۵ ~ ۲ Vpp, 75 |
| Termination | BNC |
| Physical Specifications | Dimensions mm: 133 x 442 x 311 Weight g: 5220 |
| Electrical Specifications | Voltage: 230 V Power Consumption: 25 W |
| Environmental Specifications | Operating Temperature oC: -7 ~ +49 Operating Humidity %: 10 ~ 90, non-condensing |
| Analogue Switcher Type | Matrix Switchers |
| Additional info | The CM6800E Matrix switcher/controller is a very affordable solution for medium-sized matrix switch applications. This fully integrated and highly versatile cross-point matrix switcher provides switching and control from any one of up to 18 keyboards This switcher can also be used to control other devices, such as Genex multiplexers. The CM6800E provides easy to use, passwordprotected, on-screen programming menus. Eight languages are supported. |
| Download |
