GLC-T Specification | |
| General | |
| Device Type | SFP (mini-GBIC) transceiver module |
| Form Factor | Plug-in module |
| Networking | |
| Connectivity Technology | Wired |
| Cabling Type | 1000Base-T |
| Data Link Protocol | GigE |
| Data Transfer Rate | 1 Gbps |
| Max Transfer Distance | 328 ft |
| Features | Full duplex capability, auto-negotiation, auto-uplink (auto MDI/MDI-X) |
| Compliant Standards | IEEE 802.3 |
| Expansion / Connectivity | |
| Interfaces | 1 x Ethernet 1000Base-T – RJ-45 |
| Compatible Slots | 1 x SFP (mini-GBIC) |
| Miscellaneous | |
| MTBF | 1,000,000 hours |
| Compliant Standards | CISPR 22 Class A, EN55024, EN55022 Class A, FCC Part 15 A, VCCI Class A |
| Dimensions & Weight | |
| Width | 0.5 in |
| Depth | 2.8 in |
| Height | 0.6 in |
| Manufacturer Warranty | |
| Service & Support | Limited warranty – 90 days |
| Environmental Parameters | |
| Min Operating Temperature | 32 °F |
| Max Operating Temperature | 158 °F |
| Compatibility Information | |
| Designed For | Cisco 5508 Wireless Controller ¦ Cisco Catalyst 2970G-24TS, 3560-12PC, 3560-12PC-S, 3560-24PS EMI, 3560-24PS SMI, 3560-24TS, 3560-24TS EMI, 3560-24TS SMI, 3560-48PS, 3560-48PS EMI, 3560-48PS SMI, 3560-48TS, 3560-48TS EMI, 3560-48TS SMI, 3560E-12D, 3560E-12SD-E, 3560E-12SD-S, 3560E-24PD, 3560E-24TD, 3560E-48PD, 3560E-48PD-F, 3560E-48TD, 3560E-48TD-SD, 3560G-24PS, 3560G-24PS EMI, 3560G-24PS SMI, 3560G-24TS, 3560G-24TS EMI, 3560G-24TS SMI, 3560G-48, 3560G-48PS, 3560G-48PS EMI, 3560G-48PS SMI, 3560G-48TS, 3560G-48TS EMI, 3560G-48TS SMI, 3560X-24P-L, 3560X-24P-S, 3560X-24T-L, 3560X-24T-S, 3560X-48PF-L, 3560X-48PF-S, 3560X-48P-L, 3560X-48P-S, 3560X-48T-L, 3560X-48T-S |
