| Subtypes | |
| PD1103Z2-EI | PTZ IP network |
| Basic Features | |
| Resolution | 3MP |
| Image sensor type | 1/3’’ |
| Max. frames per second (fps) | 3MP@60fps |
| Indoor / outdoor | Outdoor |
| Day / night | Day/Night |
| Built in ir | √ |
| Wide Dynamic Range | 120dB |
| ONVIF conformant | √ |
| Built-in microphone | √ |
| Power over Ethernet (PoE) | Hi-PoE |
| Advanced Features | |
| Compression | H.264/MJPEG |
| Multi-streaming | 3 streams |
| Intelligent Dynamic Noise Reduction | √ |
| Intelligent streaming | X |
| Intelligent Auto Exposure | X |
| Remote commissioning | X |
| Privacy masking | √ |
| Region Of Interest (ROI) & E-PTZ | √ |
| Region Of Interest tracking | √ |
| No. of presets / guard tours | √ |
| Wiper | X |
| Thermal | X |
| Alarm triggering | |
| Video analytics at the edge | √ |
| Tamper detection | √ |
| Video motion detection | √ |
| Audio detection | √ |
| Face detection | √ |
| PTZ Intelligent Tracking | X |
| Sensitivity | |
| Min. illumination day mode (color) | 0.05 lux |
| Min. Illumination night mode (B/W) | 0.01 lux |
| Starlight (extreme low-light) | X |
| Integrated IR-lighting | √ |
| Optional IR-lighting | X |
| Lens | |
| Automatic Back Focus (ABF) | √ |
| Varifocal | √ |
| Automatic Varifocal (AVF) | √ |
| Iris control | X |
| Focal length from | 4.5 mm |
| Focal length till | 162 mm |
| Horizontal Angle of View (HAoV) | 54.5º ~ 2.7º |
| Min. view angle (H) | N/A |
| Min. view angle (V) | N/A |
| Max. view angle (H) | N/A |
| Max. view angle (V) | N/A |
| DCRI distances (in m with 100 lux illumination) | |
| Detection | N/A |
| Classification | N/A |
| Recognition | N/A |
| Identification | N/A |
| Storage | |
| (micro)SD card slot | √ |
| Direct-to-iSCSI | X |
| Cloud storage | X |
| Connections | |
| Alarm input / output | √ |
| Audio in/out | √ |
| Hybrid | X |
| Confrontation monitor | X |
| 12VDC power output | X |
| Housing | |
| Weather rating | IP66 |
| Vandal resistant | IK10 |
| Corrosion resistant | X |
| Operating temperature | -40 °C – +65 °C (-40 °F – +149 °F |
| Downloads | |
| Datasheet (EN) | Download |
